Henan Tianchi Instrument & Equipment Co., Ltd.
Self-pressurized cryogenic vessels
Companies large-scale and variety
as many as models complete, low prices
what's app:tianchiydg
TIANCHI YDZ-75 factory price self-pressurized cryogenic vessel in TG
Over the years, the company fully utilized the key technology and advantages of the war industry and developed many kinds of cryogenic vessels with different specifications, which are widely used in the fields of spaceflight and aviation, medical treatment, biology and stock breeding.
Model:YDZ-75
Geometric volume:83L
Effective volume:75L
Overall Dimension(diameter×height):506x1180
Empty weight(Kg):56
Working pressure(Mpa):<0.1
Daily boiling-off rate (%):≤2.8
Drainage volume(L/Min):≥6
Handling and Storage:
Use a suitable hand truck for container movement.Containers should be handled and stored in an upright position.Do not drop, tip, or roll containers on their sides.Do not remove or interchange connections.Contact the vendor if you experience any difficulty operating the container valve or with the container connections.Discontinue use.Use the proper connection.DO not use adapters! Use piping and equipment designed to withstand the pressures to be encountered. On gas withdrawal systems, use a check valve or other protective apparatus in any line or piping from the container to prevent reverse flow.
To prevent cryogenic liquids or cold gas from being trapped in piping between valves, the piping should be equipped with pressure relief devices. Only transfer lines designed for use with cryogenic liquids should be used. Some elastomers and metals such as carbon steel may become brittle at low temperatures and will easily fracture. These materials must be avoided in cryogenic service. It is recommended that all vents be piped to the exterior of the building.
